Dixon Valve & Coupling
1094U5601 DIXON 100' BLACK POLYURETHANE 95 DURO TUBING, 1/4 OD, .160 ID, .045 WALL

Mouse over image to zoom, click to enlarge

Description: Legris by Dixon® Tubing, 0.16 in Inside Dia, 1/4 in Outside Dia, 100 ft Length, 0.045 in Wall Thickness, 148 psi Working, -40 to 165 deg F, Polyurethane, Black, Domestic

Manufacturer PN: 1094U5601

UPC:  69746411975

Forberg Smith PN: 3572767

Invoice Description:

1094U5601 DIXON 100' BLACK POLYURETHANE 95 DURO TUBING, 1/4 OD, .160 ID, .045 WALL

UNSPSC: 39120000


SPEC SHEET

How Can We Make This Page Better?

Legris by Dixon® 1094U5601 Tubing, 0.16 in ID x 1/4 in OD x 100 ft L x 0.045 in THK Wall, Polyurethane, Domestic

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Legris by Dixon® Tubing, 0.16 in Inside Dia, 1/4 in Outside Dia, 100 ft Length, 0.045 in Wall Thickness, 148 psi Working, -40 to 165 deg F, Polyurethane, Black, Domestic

Specifications

 Application Polyurethane Tubing Has High Flexibility and A Small Bend Radius and Thus Is Very Good For Applications Where Space Is Tight
 Brand Name Legris by Dixon®
 Color Black
 Domestic or Import Domestic
 Inside Diameter 0.16 in
 Length 100 ft
 Manufacturer Part Number 1094U5601
 Material Polyurethane
 PART NUMBER KEYWORDS 1094U5601 ; 089109847631 ; 08910984763 ; 89109847631
 Temperature Rating -40 to 165 deg F
 Working Pressure 148 psi

Features

▪ 95 durometer polyurethane
▪ For applications where the tubing will be exposed, black tubing is recommended
▪ Working pressure given at 75 deg F
▪ Warning: this product contains a chemical known to the State of California to cause birth defects or other reproductive harm
▪ Do not use in connection with drinking water
▪ Wash hands after handling
