Dixon Valve & Coupling
1520-DA-AL 2" MC X 1-1/2" FC ALUM

Mouse over image to zoom, click to enlarge

Description: Dixon® Cam and Groove Reducing Coupler, Type DA, Reducing Coupling Fitting/Connector, 2 x 1-1/2 in Nominal, Coupler x Adapter End Style, 6-5/16 in Length, 250 psi Pressure, Aluminum, Domestic

Manufacturer PN: 1520-DA-AL

UPC:  69746406712

Forberg Smith PN: 3169707

Invoice Description:

1520-DA-AL 2" MC X 1-1/2" FC ALUM

UNSPSC: 40141734


SPEC SHEET

How Can We Make This Page Better?

Dixon® 1520-DA-AL Type DA Cam and Groove Reducing Coupler, 2 x 1-1/2 in Nominal, Coupler x Adapter End Style, Aluminum, Domestic

Price:  $64.91 / ea

Note: Lead times are estimates only


Availability: 1-2 weeks


Quantity  ea Add to Cart

Description

Dixon® Cam and Groove Reducing Coupler, Type DA, Reducing Coupling Fitting/Connector, 2 x 1-1/2 in Nominal, Coupler x Adapter End Style, 6-5/16 in Length, 250 psi Pressure, Aluminum, Domestic

Specifications

 Application Designed for use with liquids
 Brand Name Dixon®
 Domestic or Import Domestic
 End Style Coupler x Adapter
 Fitting Type Reducing Coupling
 Length 6-5/16 in
 Manufacturer Part Number 1520-DA-AL
 Material Aluminum
 Nominal Size 2 x 1-1/2 in
 Pressure Rating 250 psi
 Type Type DA
 Video Links

Features

▪ Wash hands after handling
▪ 7-7/16 in open across cam arm
▪ Buna-N gasket
▪ Produced to interchange with all product produced to commercial item description A-A-59326D
▪ Produced as a welded fabrication construction
▪ In reducing couplings, the coupler is the first size in the part number
▪ Under no circumstances should cam and groove couplings be used for compressed air or steam service!
▪ Pressure rating recommendations are based on the use of mating Dixon fittings at ambient temperature 70 deg F with a standard seal installed
▪ Warning: this product contains a chemical known to the state of California to cause birth defects or other reproductive harm
▪ Do not use in connection with drinking water

Resources

 Catalog
 Catalog Page
 Product Data Sheet
