Viega
  • 26810 2-1/2X3/4 MEGAPRESS XL CS PRESS-IN BRANCH CONNECTOR PROPXFIP FKM SEAL
  • 26810 2-1/2X3/4 MEGAPRESS XL CS PRESS-IN BRANCH CONNECTOR PROPXFIP FKM SEAL

Description: MegaPress® Branch Connector, Press-In, Series: 4812.2, Fitting/Connector Type: Branch Connector, 2-1/2 x 3/4 in Nominal, Press x FNPT, SCH 10, 200 psi, 284 deg F, Carbon Steel, Zinc Nickel Coated, Import

Manufacturer PN: 26810

UPC:  69151426810

Forberg Smith PN: 4186648

Invoice Description:

26810 2-1/2X3/4 MEGAPRESS XL CS PRESS-IN BRANCH CONNECTOR PROPXFIP FKM SEAL

UNSPSC: 40183110


How Can We Make This Page Better?

MegaPress® 26810 4812.2 Press-In Branch Connector, 2-1/2 x 3/4 in Nominal, Press x FNPT End Style, Carbon Steel, Import

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

The MegaPress® Press-in Branch Connector is designed for SCH 10 and SCH 40/STD carbon steel pipes. The press-in branch connector creates a 3/4 in NPT threaded connection in accordance with ASME B1.20.1. It is particularly suitable where space is at a premium, e.g. in pipe manifold installation for sensors, thermometers or drains. A separate press-in branch connector is available for the different pipe dimensions. The press-in branch connector is fitted with a sealing element made of EPDM or FKM. The press-in branch connectors are marked with a green dot for EPDM and a white dot for FKM. The Viega MegaPress® Press-in Branch Connector requires no welding and poses no fire hazard, which is particularly important in restoration or retrofit work. The press fittings are installed with a battery-powered or corded pressing tool.
MegaPress® Branch Connector, Press-In, Series: 4812.2, Fitting/Connector Type: Branch Connector, 2-1/2 x 3/4 in Nominal, Press x FNPT, SCH 10, 200 psi, 284 deg F, Carbon Steel, Zinc Nickel Coated, Import

Specifications

 Application For black/galvanized/industrially painted/powder coated seamless steel pipes and fire protection applications
 Brand Name MegaPress®
 Domestic or Import Import
 End Style Press x FNPT
 Finish Zinc Nickel Coated
 Fitting Type Branch Connector
 Includes FKM Sealing Element
 Manufacturer Part Number 26810
 Material Carbon Steel
 Nominal Size 2-1/2 x 3/4 in
 PART NUMBER KEYWORDS 26810 ; ; 691514268101 ; 69151426810 ; 30691514268102
 Pressure Rating 200 psi
 Schedule Rating SCH 10
 Series 4812.2
 Standards/Approvals ABS Approved|ASME B1.20.1|CRN 14541.5 A/B/C|DNV-GL Approved|FM Approved|IAMPO IGC-353|UL Listed
 Temperature Rating 284 deg F
 Type Press-In

Features

▪ Engineered with a 420 stainless steel grip ring plus a 304 stainless steel separator ring for sizes 1/2 in to 2 in and a PBT separator ring for sizes 2-1/2 in to 4 in fittings
▪ Approved for more applications than any other carbon steel pipe press fitting system
▪ Suitable for use with ASTM SCH 5 to SCH 40/STD carbon steel pipe (can be used on higher schedule pipe, but limited to maximum pressure listed)
▪ Corrosion-resistant zinc nickel coating
▪ Over 180 engineered fitting configurations from 1/2 in to 4 in
▪ Approved for underground applications, in accordance with code and local AHJ
▪ The same hanger and support requirements as threaded systems
▪ Viega Smart Connect® technology provides installers added confidence in their ability to ensure secure connections
▪ Not approved for use with SCH 10, 1/2 in to 1 in pipe where UMC codes apply
