Dixon Valve & Coupling
61-201 DIXON 1/4 BRS CHECK VLV

Mouse over image to zoom, click to enlarge

Description: Dixon® Ball Cone Check Valve, 1/4 in Nominal, MNPT x FNPT End Style, 400 psi WOG, 125 psi WSP Pressure, -20 to 353 deg F, Media: Gas/Oil/Steam/Water, Brass Body, PTFE Seat Softgoods

Manufacturer PN: 61-201

UPC:  69746412328

Forberg Smith PN: 4071400

Invoice Description:

61-201 DIXON 1/4 BRS CHECK VLV


How Can We Make This Page Better?

Dixon® 61-201 Ball Cone Check Valve, 1/4 in Nominal, MNPT x FNPT End Style, Brass Body, PTFE Seat Softgoods

Log In for Pricing and Availability

Note: Lead times are estimates only




Description

Dixon® Ball Cone Check Valve, 1/4 in Nominal, MNPT x FNPT End Style, 400 psi WOG, 125 psi WSP Pressure, -20 to 353 deg F, Media: Gas/Oil/Steam/Water, Brass Body, PTFE Seat Softgoods

Specifications

 Application For domestic applications
 Body Material Brass
 Brand Name Dixon®
 End Style MNPT x FNPT
 Manufacturer Part Number 61-201
 Nominal Size 1/4 in
 PART NUMBER KEYWORDS 61-201 ; 61201
 Pressure Rating 400 psi WOG, 125 psi WSP
 Softgoods Material PTFE Seat
 Temperature Rating -20 to 353 deg F

Features

▪ Tight shut-off with liquid media
▪ No radial alignment necessary
▪ Straight through and streamlined for minimum change in velocity
▪ Reinforced PTFE check is spring loaded for fast seating action
▪ 0.5 psi cracking pressure
