Ashcroft Inc
63MM ( 25 ) 1008A 02L 30# ASHCROFT 25L30 1/4 LM

Mouse over image to zoom, click to enlarge

Description: Ashcroft® Pressure Gauge, Dry, Series: 1008A, 0 to 30 psi, 1/4 in MNPT, 2-1/2 in Diameter Dial, +/- 3-2-3 % Accuracy, Graduations: 0.2 psi, Liquid Filled: No, Dial Display, -40 to 158 deg F, Lower Mount, 304 Stainless Steel/Brass/Bronze/Polycarbonate, 2.71 in Dia x 1.21 in D Dimensions

Manufacturer PN: 662876209521

UPC:  662876209521

Forberg Smith PN: 3023582

Invoice Description:

63MM ( 25 ) 1008A 02L 30# ASHCROFT 25L30 1/4 LM

UNSPSC: 41112400


SPEC SHEET

▸ See All in Ashcroft Industrial Gauges


How Can We Make This Page Better?

Ashcroft® GA631008A02L 0-30 Dry Pressure Gauge, 0 to 30 psi Pressure, 1/4 in MNPT Connection, 2-1/2 in Dia Dial, +/- 3-2-3 % Accuracy, 0.2 psi Graduation

Price:  $23.84 / ea


Availability: 7 ea  i


Quantity  ea Add to Cart

Description

The Ashcroft® 1008A Series Pressure Gauge offers exceptional quality, durability and performance. The sealed case protects from ambient conditions and includes features enhancing product performance and safety. An ideal gauge for satisfying applications with high levels of vibration, pulsation and pressure spikes.
Ashcroft® Pressure Gauge, Dry, Series: 1008A, 0 to 30 psi, 1/4 in MNPT, 2-1/2 in Diameter Dial, +/- 3-2-3 % Accuracy, Graduations: 0.2 psi, Liquid Filled: No, Dial Display, -40 to 158 deg F, Lower Mount, 304 Stainless Steel/Brass/Bronze/Polycarbonate, 2.71 in Dia x 1.21 in D Dimensions

Specifications

 Accuracy +/- 3-2-3 %
 Application Commercial, Industrial Market, Pump and Compressor, Hydraulic, Pneumatic, OEM Equipment, Pressure Washers/Sprayer and Irrigation Equipment Applications
 Brand Name Ashcroft
 Connection Size 1/4 in MNPT
 Dial Diameter 2/1/2002 in
 Dimensions 2.71 in Dia x 1.21 in D
 Graduations 0.2 psi
 Liquid Filled No
 Manufacturer Part Number GA631008A02L 0-30
 Material 304 Stainless Steel/Brass/Bronze/Polycarbonate
 Mounting Type Lower
 Pressure Rating 0 to 30 psi
 Series 1008A
 Standards/Approvals ASME B40.100 Grade B|CRN Listed
 Temperature Rating -40 to 158 deg F
 Type Dry

Features

▪ PowerFlex™ movement provides superior resistance to shock, vibration and pulsation - extends product life and reduces maintenance costs
▪ True Zero™ reduces reading errors by using a "zero zone" instead of conventional dial pins (posts), this ensures product safety, integrity and system control
▪ Ventable fill plugs
▪ Rugged construction suited for harsh environmental conditions
▪ Can be customized for a variety of applications
▪ 304 stainless steel case, bronze bourdon tube, polycarbonate window and brass process connection
