(D) 2 GALV CI COMPANION FLG

Mouse over image to zoom, click to enlarge

Description: Ward Mfg Companion Flange, 2 in Nominal, 0.62 in Thickness, 4-3/4 in Bolt Circle, 4 Bolt Holes, 3/4 in, Thread, 6 in Outside Dia, 175 psi, 125 lb, SCH 40/STD, -20 to 150 deg F, 3.06 in Hub Dia, Cast Iron, Galvanized, 1 in L, Domestic;Anvil® Flange, 2 in Nominal, Thread Connection, 7-1/2 in OD, Cast Iron, Galvanized, Domestic/Import: Domestic

Manufacturer PN: 0309002806

UPC:  66246744565

Forberg Smith PN: 3032796

Invoice Description:

(D) 2 GALV CI COMPANION FLG


SPEC SHEET

How Can We Make This Page Better?

Ward Mfg 0309002806 Companion Flange, 2 in, Cast Iron, Thread, 125 lb, Domestic;Anvil® 0309002806 Flange, 2 in Nominal, Cast Iron, Thread Connection, Galvanized, Domestic

Log In for Pricing and Availability




Description

Ward Mfg Companion Flange, 2 in Nominal, 0.62 in Thickness, 4-3/4 in Bolt Circle, 4 Bolt Holes, 3/4 in, Thread, 6 in Outside Dia, 175 psi, 125 lb, SCH 40/STD, -20 to 150 deg F, 3.06 in Hub Dia, Cast Iron, Galvanized, 1 in L, Domestic;Anvil® Flange, 2 in Nominal, Thread Connection, 7-1/2 in OD, Cast Iron, Galvanized, Domestic/Import: Domestic

Specifications

 Bolt Circle Diameter 4-3/4 in
 Bolt Hole Size 3/4 in
 Brand Name Ward Mfg;Anvil®
 Connection Type Thread
 Dimensions 1 in L
 Domestic or Import Domestic
 Finish Galvanized
 Hub Diameter 3.06 in
 Manufacturer Part Number 0309002806
 Material Cast Iron
 Nominal Size 2 in
 Number of Bolt Holes 4
 PART NUMBER KEYWORDS 0309002806 ; 2X6.NCF ; 2X6NCF ; 662467445659 ; 66246744565;0309002806 ; 690291022555 ; 69029102255
 Pressure Rating 175 psi
 Schedule Rating SCH 40/STD
 Standards/Approvals ANSI B16.1/B1.20.1|ASTM A126/A153|FM Approved|NSF 61-G|UL/ULC Listed|WW F521
 Temperature Rating -20 to 150 deg F

Features

▪ Threaded companion flanges offer an economical way to convert the plain end of a pipe to a flanged connection

Resources

 Product Data Sheet
