(D) 4X4X2-1/2 GALV MALL TEE

Mouse over image to zoom, click to enlarge

  • (D) 4X4X2-1/2 GALV MALL TEE
  • (D) 4X4X2-1/2 GALV MALL TEE

Description: Anvil® Pipe Reducing Tee, Standard, Series: FIG 1105R, Fitting/Connector Type: Tee, 4 x 4 x 2-1/2 in Nominal, FNPT, SCH 40/STD, 150 lb, 300 psi, Malleable Iron, Galvanized, -20 to 150 deg F, Domestic

Manufacturer PN: (D)

UPC:  69029103029

Forberg Smith PN: 3026402

Invoice Description:

(D) 4X4X2-1/2 GALV MALL TEE

UNSPSC: 40142300


SPEC SHEET

How Can We Make This Page Better?

Anvil® 0311056808 FIG 1105R Standard Pipe Reducing Tee, 4 x 4 x 2-1/2 in Nominal, FNPT End Style, 150 lb, Malleable Iron, Galvanized, Domestic

Price:  $892.89 / ea

Note: Lead times are estimates only


Availability: 2-4 weeks


Quantity  ea Add to Cart

Description

Anvil International offers the broadest line of malleable iron fitting sizes in both black and galvanized finishes. Every fitting is manufactured and tested to meet Anvil's strict quality standards. All Anvil Class 150 Malleable Iron Fittings conform to ASME B16.3 and unions conform to ASME B16.39. All elbows and tees 3/8 in (10 DN) and larger are 100% gas tested at a minimum of 100 PSI (6.9 bar).
Anvil® Pipe Reducing Tee, Standard, Series: FIG 1105R, Fitting/Connector Type: Tee, 4 x 4 x 2-1/2 in Nominal, FNPT, SCH 40/STD, 150 lb, 300 psi, Malleable Iron, Galvanized, -20 to 150 deg F, Domestic

Specifications

 Brand Name Anvil®
 Domestic or Import Domestic
 End Style FNPT
 Finish Galvanized
 Fitting Type Tee
 Manufacturer Part Number 0311056808
 Material Malleable Iron
 Nominal Size 4 x 4 x 2-1/2 in
 Pressure Rating 300 psi
 Schedule Rating SCH 40/STD
 Series FIG 1105R
 Standards/Approvals ASME B16.3/B1.20.1|ASTM A197|cULus Listed|FM Approved|NSF/ANSI 61
 Temperature Rating -20 to 150 deg F
 Type Standard

Features

▪ Malleable iron pipe fittings hold two different pipe parts together and direct gas and liquid movement.
