Neles Corporation
MGR7/QA MANUAL GEAR OPERATOR WITH HAND WHEEL

Mouse over image to zoom, click to enlarge

Description: Jamesbury™ Manual Gear Actuator, Model A 1/4 Turn, Series: MGR, 19 mm Size, For Use With: Jamesbury™ Ball and Butterfly Valves, Specifications: 150 to 26000 N-m Torque, -4 to 176 deg F Temperature, Cast Iron, Polyurethane Coated

Manufacturer PN: 097 0189 00

Forberg Smith PN: 3055045

Invoice Description:

MGR7/QA MANUAL GEAR OPERATOR WITH HAND WHEEL

UNSPSC: 39120000


SPEC SHEET

How Can We Make This Page Better?

Jamesbury™ 097 0189 00 MGR Model A 1/4 Turn Manual Gear Actuator, 19 mm, For Use With Jamesbury™ Ball and Butterfly Valves, Cast Iron

Price:  $458.53 / ea
Price not maintained - Will need to be verified


Note: Lead times are estimates only


Availability: 2-4 weeks


Quantity  ea Add to Cart

Description

The quarter turn MGR series manual gear actuator has been engineered to meet the requirements of demanding industrial environments. It has a cast iron construction and high performance axial bearings to enable smooth and accurate operation. The enclosure is sealed to IP67 and polyurethane painted for corrosion protection. They are factory lubricated for their lifetime. MGR series gear actuators are recommended for use on Jamesbury™ ball and butterfly valves. For the sake of convenience and lever handles present space problems, gear actuators are the ideal choice. MGR series actuators are available factory mounted on valves or separately for field installation.
Jamesbury™ Manual Gear Actuator, Model A 1/4 Turn, Series: MGR, 19 mm Size, For Use With: Jamesbury™ Ball and Butterfly Valves, Specifications: 150 to 26000 N-m Torque, -4 to 176 deg F Temperature, Cast Iron, Polyurethane Coated

Specifications

 Application For reliable and economical operations
 Brand Name Jamesbury™
 Finish Polyurethane Coated
 Manufacturer Part Number 097 0189 00
 Material Cast Iron
 Series MGR
 Size 19 mm
 Specifications 150 to 26000 N-m Torque, -4 to 176 deg F Temperature
 Suitable For Use With Jamesbury™ Ball and Butterfly Valves
 Type Model A 1/4 Turn

Features

▪ Proven performance
▪ Handwheel without padlock flange
▪ 19 mm female square size
▪ Cast iron body with metal gears and bearings
▪ ISO 5211 mounting pattern
▪ Fully enclosed and weather-proof
▪ Factory lubricated for their lifetime
▪ Adjustable stops for both open and closed positions
▪ Highly visible position indication pointer
▪ Long life
▪ Low maintenance
▪ Easy to operate
