| Accuracy | Typically ?2% of reading |
| Adapter Material | PVC |
| Electrical Cable For Insert Electronics | 36 inches (914.4 mm) of 18 AWG, solid cop per, ?Direct Burial? (UL 493 & 83) |
| Insert Wetted Materials Body | PPS (Ryton R-4) |
| Insert Wetted Materials O Ring | EPDM |
| Insert Wetted Materials Sensor | PEI (Ultem 1000) |
| Maximum Water Pressure | 150 psi @ 73?F (10 bar @ 23?C);100 psi @ 140? F (7 bar @ 60? C) |
| Meter Material | RYTON |
| Operating Range Max | INSERT ONLY |
| Operating Range Min | INSERT ONLY |
| Operating Temperature Rating | 32? F to 140? F (0? C to 60? C) |
| Output Frequency | 0 to 100 Hz |
| Output Pulse Width | 4 ms |
| Pipe Size | INSERT ONLY |
| Process Port | N/A |
| Tee Housing Material | SCHEDULE 80 PVC |
| Tee Material | N/A |
| Transducer Excitation Quiescent Current | 200 ?A (typical) |
| Transducer Excitation Supply Voltage | 7.5V (dc) min. to 36V (dc) max |
