Matco-Norca
1-1/2X6 LG CLAMPETTE REPAIR CLAMP 330-076

Mouse over image to zoom, click to enlarge

Description: Matco-Norca™ Pipe Patch Clamp, 330 Series, 1-1/2 in Pipe, 304 Stainless Steel, 6 in W, -50 to 240 deg F, Domestic

Manufacturer PN: 330-076

Forberg Smith PN: 3056734

Invoice Description:

1-1/2X6 LG CLAMPETTE REPAIR CLAMP 330-076


SPEC SHEET

How Can We Make This Page Better?

Matco-Norca™ 330-076 Pipe Patch Clamp, 1-1/2 in Pipe, 304 Stainless Steel, Domestic

Log In for Pricing and Availability




Description

Matco-Norca™ Pipe Patch Clamp, 330 Series, 1-1/2 in Pipe, 304 Stainless Steel, 6 in W, -50 to 240 deg F, Domestic

Specifications

 Application For IPS pipe
 Brand Name Matco-Norca™
 Dimensions 6 in W
 Domestic or Import Domestic
 Manufacturer Part Number 330-076
 Material 304 Stainless Steel
 PART NUMBER KEYWORDS 330-076 ; 330076 ; 670388201506 ; 67038820150
 Pipe Size 1-1/2 in
 Series 330
 Standards/Approvals ASTM F844 Washer
 Temperature Rating -50 to 240 deg F

Features

▪ SAE flat washer
▪ Gasket: Gridded nitrile buna rubber is especially resistant to aromatic hydrocarbons, gasoline, petroleum oils, mineral oils, vegetable oils and natural gas
▪ 150 psi
▪ No loose parts
▪ Can be installed with one hand
▪ Round corners with sheared edges turned down, eliminating the danger of small cuts or nicks during installation
▪ A long carriage bolt with extra large shoulder that prevents the bolt from spinning during installation
▪ A double chamfered oversized nut that allows easy hand tightening
▪ Stainless steel band: Double slit so that edges on both sides of clamp turn under, this eliminates sharp edges which would cut your hand
▪ Lugs: Malleable iron electro galvanized with dichromate finish
▪ Bolts: Carbon steel electro galvanized with dichromate finish
▪ Nuts: Carbon steel electro galvanized with dichromate finish

Resources

 Product Data Sheet
